SDS series

Description

Item	SDS 0.9	SDS 1.2	SDS 1.5	SDS 1.6	SDS 1.8
Pixel Pitch	0.9375 mm	1.25 mm	1.5625 mm	1.667 mm	1.875 mm
Max Brightness Calibrated	300 nits (black)	400 nits (black)	400 nits (black)	500 nits (black)	500 nits (black)
Panel Dimension	600 x 337.5 x 40 mm	600 x 337.5 x 40 mm	600 x 337.5 x 40 mm	600 x 337.5 x 40 mm	600 x 337.5 x 40 mm
Panel Resolution ( H x V )	640 x 360	480 x 270	384 x 216	360 x 202	320 x 180
Frame Material	Diecasting Aluminum Alloy	Diecasting Aluminum Alloy	Diecasting Aluminum Alloy	Diecasting Aluminum Alloy	Diecasting Aluminum Alloy
Weight Per Panel	8 kg	8 kg	8 kg	8 kg	8 kg
Power Consumption Max / Average	1000 W / 500 W Per ㎡	1000 W / 500 W Per ㎡	800 W / 400 W Per ㎡	800 W / 400 W Per ㎡	800 W / 400 W Per ㎡
Transparency	Solid	Solid	Solid	Solid	Solid
Serviceability	Front / Rear	Front	Front	Front	Front
Curving (Concave & Convex)	Custom 10° ~ 15°	N/A	N/A	N/A	N/A
SMD Configuration	SMD1616 Black	SMD1212 Black	SMD1212 Black	SMD1212 Black	SMD1515 Black
Physical Density	1,137,777Pixels / ㎡	640,000 Pixels / ㎡	409,600 Pixels / ㎡	359,111 Pixels / ㎡	284,444 Pixels / ㎡
Viewing Angle ( H / V)	160° / 140°	140° / 140°	140° / 140°	140° / 140°	140° / 140°
Refresh Rate	3840 Hz	3840 Hz	3840 Hz	3840 Hz	3840 Hz
Gray Scale	14 bit	14 bit	14 bit	14 bit	14 bit
Scan Ratio	1/60	1/27	1/54	1/26	1/60
Operational Temp / Humidity	– 20° ~ 45°C / 10-90% RH	– 20° ~ 45°C / 10-90% RH	– 20° ~ 45°C / 10-90% RH	– 20° ~ 45°C / 10-90% RH	– 20° ~ 45°C / 10-90% RH
Storage Temp / Humidity	– 40° ~ 60°C / 10-90% RH	– 40° ~ 60°C / 10-90% RH	– 40° ~ 60°C / 10-90% RH	– 40° ~ 60°C / 10-90% RH	– 40° ~ 60°C / 10-90% RH
IP Rating (Front / Rear)	IP30 / IP30 Indoor	IP30 / IP30 Indoor	IP30 / IP30 Indoor	IP30 / IP30 Indoor	IP30 / IP30 Indoor
