Description
G10
INSULATION BOARD
≥ 340 MPa
Flexural strength
perpendicular to laminations
≥ 33 KJ/m²
Charpy impact
strength parallel to laminations
≥ 35 Kv
Electric strength perpendicular to
laminations(at 90℃ in 25# transformer oil)
≥ 5*(10²*10²) MΩ
Insulation resistance
after immersion in water
UL94-HB Level
Combustibility
30 mg
Water absorption
120℃
TG
High mechanical strength at room temperature, strong mechanical strength at high temperature of 120℃, good electrical performance in dry and wet state, flame retardant.
