Description
https://www.guangyumotorcycle.com/KN110-10A.html
Urban commuting, short-distance travel
Lightweight and flexible, low fuel consumption
PRODUCT PARAMETERS
| ENGINE TYPE 110cc,air-cooled,4 Stroke | ||
| Displacement | 119.6ml | |
| Bore&Stroke | 52.4×55.5mm | |
| Compression Ratio | 9.0:1 | |
| Max Power(Kw/rpm) | 5.3Kw/8000(r/min | |
| Max Torque(N.M/rpm) | 8.0N.m/6000rpm | |
| Max Speed | 75kmph | |
| Accelerate | 15s | |
| Beyond the acceleration | 14s | |
| Engine Oil | 1.0L | |
| Clutch Type | Multi-disc wet clutch,automatic | |
| lgnition | CDI | |
| Spark plug | A7TC | |
| Starting System | Electric+Kick start | |
| Transmission System | Chain drive | |
| Final drive ratio | 14:38 | |
| Size | 1930×700×1160mm | |
| Seat Height | 770mm | |
| Wheelbase | 1240mm | |
| Min.Ground Clearance | 160mm | |
| Max.Permissionable | 150Kg | |
| Steering Angle how | 35 | |
| How the side stand tilt Angle | 13 | |
| Rider Capacity | 1 Person | |
| Dry.Weight | 95kg | |
| Fuel Tank Capacity | 4L | |
| Brakes Front | Disc Brake | |
| Brakes Rear | Drum Brake | |
| Front Tire | 2.50-17 | |
| Rear Tire | 2.75-17 | |
| Battery | 12V/5Ah | |
| 40HQ(SKD) | 105 | |
| 40HQ(CKD) | 188 | |
