Small Internally Illuminated Sign

Description

The Small Internally Illuminated Sign is a high-visibility traffic signage solution designed with an integrated aluminum alloy frame and built-in edge-lit structure. It incorporates a light guide plate system to achieve uniform illumination across the entire sign surface.

Compared with conventional reflective signage, this internally illuminated design provides active light emission, ensuring clear visibility in both daytime and nighttime environments. Under adverse weather conditions such as rain, fog, or low-light scenarios, visibility performance can be significantly improved—up to several times higher than standard passive reflective signs.

The product is widely applied in urban roads, expressways, and highway traffic systems, supporting both safety management and visual guidance while maintaining low energy consumption and modern urban aesthetics.

Key Functional Features

Uniform Illumination with High Visibility

The sign adopts full-surface light guide technology combined with LED optical design to ensure even brightness distribution. This reduces glare and eliminates dark zones, providing consistent visual clarity under all lighting conditions.

Slim and Durable Structural Design

The frame is made of a one-piece aluminum alloy structure, offering strong mechanical stability and long service life. With an ultra-thin profile of ≤12mm, the design maintains a clean and modern appearance suitable for urban infrastructure applications.

Dual Power Compatibility

The system supports both solar power and AC mains power supply, allowing flexible installation in different environments. It also supports multiple operating modes, including continuous lighting and programmable flashing patterns.

Intelligent Warning Integration

The sign can be integrated with radar detection systems to enable real-time traffic warnings. This enhances active safety functions by providing dynamic alerts based on approaching vehicles or pedestrians.

Technical Specifications

Available Sizes and Shapes

• Ø800mm Circular

• Ø800mm Octagonal

• Ø900mm Triangular

• 1000 × 1000mm Square

• 400 × 600mm Rectangular

Structural Configuration

• Back plate material: Aluminum alloy

• Frame thickness: 12mm aluminum alloy profile construction

Optical System

• Light source: 2835 LED with light-guiding emission technology

• Color temperature: ≥12000K cool white

• Luminous output: 25 lm per LED

• Viewing angle: 120°

Reflective Layer

• Type IV high-intensity reflective sheeting (custom options available)

Electrical Parameters

• Power supply: AC mains / Solar hybrid compatible

• Working voltage: 12V

• Rated power:

• Circular: 22W

• Octagonal / Triangular: 20W

• Square: 30W

• Rectangular: 12W

Weight Information

• Circular: 7.2 kg

• Octagonal: 6.7 kg

• Triangular: 5.2 kg

• Square: 9.5 kg

• Rectangular: 3.6 kg

Operating Modes

The system supports multiple intelligent control modes:

• Ambient light ON/OFF control (automatic response to surrounding brightness)

• Dimming adjustment based on real-time light conditions

• Solar panel voltage-based ON/OFF control

• External signal trigger control

• Time-based scheduled operation

Display Modes

• Continuous illumination

• Flashing modes: 15 times/min, 60 times/min, adjustable high-frequency mode

Optical Material

• Transparent fiberglass light-transmitting panel (thickness ≥ 1.5mm)

Performance Data

• Luminance range: 125–344 cd (measured at 3m depending on model)

• LED viewing angle: 120°

• Service life: Approximately 5 years

Environmental Performance

• Operating temperature: -25°C to +65°C

• Relative humidity: ≤95%

• Protection rating: IP55

• Visual distance: ≥800 meters
