Six Axis Injection Molding Robot Product Details
BRTIRUS2550A is a six-axis robot developed by Bronte for complex applications with multiple degrees of freedom. It has a 2550mm long reach and a maximum load of 50kg. With the flexibility of six degrees of freedom, it can handle loading and unloading, assembly, injection molding and other scenarios freely. High protection level: wrist IP54, body IP50, dust proof and waterproof. High precision: Repeat positioning accuracy ±0.1mm.
Main Specification
Arm span (mm): 3500
Repeat positioning accuracy (mm): ±0.2
Maximum load (KG): 100
Power capacity (KVA): 28
Weight (KG): about 1350
|
Project |
Scope |
Maximum Speed |
|
|
Arm |
J1 |
±160° |
84°/S |
|
J2 |
±70° |
52°/S |
|
|
J3 |
-75°/+115° |
52°/S |
|
|
Wrist |
J4 |
±180° |
145°/S |
|
J5 |
±125° |
223°/S |
|
|
J6 |
±360° |
223°/S |
|
No further notice if the specification and appearance are changed due to improvement and other reasons. Thank you for your understanding.
