RENOPI 5.12/10.24KWH LFP Battery
5.12/10.24KWH Capacity
Scalable 16 pcs
Fashionable Aesthetic
Easy Installation
≥6500 Cycles
Leading the way in family aesthetics
Industry-leading appearance design, to meet the fashionable aesthetic needs of home installation.
No LCD screen design, simple lamp language expression leads the new trend of human-computer interaction.
Adopt with LFP battery ensures safety operation and more than 6500 cycles with 80% DoD.
Each battery with independent BMS system manages power output smartly and effectively.
Technical Parameters
| RENOPI MODEL | RL-5K-WA | RL-10K-WA |
|---|---|---|
| General Parameters | ||
| Voltage | 51.2V | 51.2V |
| Battery Cell | 100AH | 200AH |
| Capacity | 5.12KWH | 10.24KWH |
| Scalability | Max.16pcs in parallel(81.92KWH) | Max.16pcs in parallel(163.84KWH) |
| Max Charge/Discharge Current | 100A | 150A |
| Peak Discharge Current | 120A(2mins,25℃) | 200A(2mins,25℃) |
| Dimensions(LxWxH) | 610*606*166mm | 860*606*166mm |
| Weight | 60.5KG | 102.5KG |
| Basic Parameters | ||
| Life Time(25°C) |
10 Years |
|
| Life Cycles(80% DOD,0.5C/0.5C,25°C) | ≥6500 Cycles | |
| Operation Temperature | -20℃～55℃ | |
| Storage Temperature | 0°C ～ 35°C | |
| IP Rating | IP21 | |
| Humidity | 5%~95% | |
| Altitude | ≤2000m | |
| Installation | Wall mounted | |
| Communication Por | CAN2.0, RS485, Bluetooth | |
| Lithium Battery Standard | UL1973, IEC62619,CE-EMC, UN38.3, MSDS | |
