Description
[Features]
1. Special Designed Sample Digestion Vessel
The auto vent and self-resealing design ensures digestion vessels can
automatically release pressure and instantly reseal when a sudden over-pressure
situation occurs. It reduces waste of batch samples and also avoids vessel
damage.
2. Contactless Temperature and Pressure Monitoring System
The imported contactless IR sensor can measure the real-time temperature of
sample solution(NOT Vessel Wall) in each digestion vessel. Meanwhile, the
contactless pressure sensor can monitor the real-time pressure of each vessel.
It avoids sample cross-contamination, and the real-time temperature and pressure
value in each vessel are displayed during the whole digestion process and
enables a clear check of digestion condition.
3. Large Storage Capacity
Up to 255 kinds of method programs can be edited and saved, each method
program can set with max. 10 steps and parameters (temperature, pressure, time,
microwave power).
4. Safety Protection System
The double locked security door, the separate protection vessel frame, the
real-time temperature and pressure monitoring system, the auto adjustment of
over-pressure and over-temperature system and the abnormal sound monitoring
ensure that a highly safe operation environment.
[Technical Specification]
|
Model |
MWD-650 |
MWD-700 |
|
|
Vessel Quantity |
12 |
18 |
|
|
TemperatureMonitoring |
Contactless IR Sensor Temperature Monitoring Each Vessel Temperature Controlled Temperature Controlling Range: 50-400℃ Max. Working Temperature: 250℃ Temperature Accuracy: ±0.1℃ |
||
|
PressureMonitoring |
Contactless Sensor Pressure monitoring Each Vessel Pressure Controlled Pressure Controlling Range: 0-15MPa Max. Working Pressure: 6Mpa Pressure Accuracy: ±0.01MPa |
||
|
Vessel Volume |
100mL |
||
|
Sample Vessel Material |
Imported TFM |
||
|
Protection VesselMaterial |
PEEK+Glass Fiber |
||
|
Display |
7 inchesColor Touch Screen |
||
|
Rotation |
One Direction 360° continuous rotating |
||
|
Microwave Cavity |
316L stainless steel cavitywith corrosion-proof coating |
||
|
Microwave Power |
0-2000W (Adjustable) |
0-3000W (Adjustable) |
|
|
Microwave Leakage |
<5mW/cm2 |
||
|
Air Exhaust |
High power corrosion-proof air blower |
||
|
Power |
AC 220V±10%, 10A, 50/60Hz |
||
