Product Features
● Heat efficient more than 95%.
● Accurate regulation and stability.
● Durable equipment, easy maintenance.
● Short pipe distance against the loss of heat.
Mechanical Part
1. Heating cylinder: 304 stainless steel for inner cylinder, carbon steel for shell.
2. Flange heater: 304 stainless steel and air inlet&outlet flange specification is DN150,1.6Mpa.
3. Sealing gasket: spiral wound gasket among flange.
4. Terminal box: A terminal box is set at top of the heating tank and the terminal box is equipped with a protective shell. The terminals of all heating pipes are arranged in the terminal box and the heating pipe terminal is drawn through the bronze plate.
5. Thermal insulation layer: the outside of the heating cylinder is installed with thermal insulation layer, alumina silicate fiber, thickness≥100mm.
6. Welding: the type and size of the welded joint in accordance with HG20583-1998
Electrical Elements
1. Temperature controller: Omron
2. Air switch: Schneider
3. Contactor: Schneider
4. Indicator light: Schneider
5. Press-button: Schneider
6. Solid-state relay: Ximaden
7. Temperature detection: from Anhui Tiankang
8. Terminal strip: from Aoyu
