Description
https://www.ascendtechs.com/FSH-CF-series-constant-flow-metering-pump-system.html
FSH-CF series is the newest pulse free high efficiency constant flow metering pump system independtly developed by Guangzhou Ascend. The system consists of a digital controller and a pulse free constant flow pump body. FSH-CF series is a high efficiency, high precision, high reliability digital control system based on micro-meter precision machining technology. The system maintains high precision dispensing with maximum injection efficiency. FSH-CF series pump system is a perfect solution for automatic injection and filling lines as well as fully automatic factories. The system can be widely used in lithium battery electrolyte injection, chemical dispensing, pharmaceutical drug dispensing, liquid food dispensing, etc.
Working Principle:
Special Constant Flow Driving Technology:
In order to maintain constant fluid flow from the system, FSH-CF pump uses a special constant flow mechanism device. The motor drives the device to complete fluid inlet and outlet dispensing cycle. The pump uses micro-meter high precision machining technology to ensure its dispensing accuracy of 0.3% or better.
Specification:
Technical Parameters:
System Features
High efficiency. Up to 40ml/s.
Pulse free. No pump jamming or leaking
High pressure. Up to 0.3MPa.
High precision. 0.3% or better.
Communication: 24V I/O; Ethernet
Drive: Step motor with closed loop control
Intuitive and easy to use.
Option of explosion proof version.
Typical Applications
Lithium battery electrolyte injection
Pharmaceutical drug filling
Chemical fluid filling
Food and beverage additions
