Description
Technical parameter (Based on 6 colors)
|
Model |
AY600A |
AY800A |
AY1100A |
|
Printing width |
600mm |
800mm |
1100mm |
|
Material width |
630mm |
830mm |
1130mm |
|
Printing cylinder diameter |
φ100-350mm |
φ100-350mm |
φ100-350mm |
|
Printing speed |
50-60m/min |
50-60m/min |
50-60m/min |
|
Unwind diameter |
600mm |
600mm |
600mm |
|
Rewind diameter |
600mm |
600mm |
600mm |
|
Register accuracy |
±0.2mm |
±0.2mm |
±0.2mm |
|
Total power |
45KW |
55KW |
66KW |
|
Weight |
5000KG |
5500KG |
6000KG |
|
Dimension |
10600*2020*2425mm |
10600*2020*2425mm |
10600*2020*2425mm |
Feature:
1. Unwind mechanical shaft, double magnetic powder brake automatic tension control
2. Infeed magnetic powder control and outfeed torque motor control
3. Main motor differential motor control
4. Rewind mechanical shaft, torque motor control
5. Shaft type printing cylinder installation
6. Manual pressing roller
7. Manual doctor blade
8. Electric heating
