Description
Product Features:
-
Equipment utilizes state-of-the-art control systems from international standards
-
Equipment operates fully automatically, ensuring minimal downtime.
-
Selectable station of let-off: rotatory dual-station and front and rear dual-station, with manual/automatic splicing of ply.
-
Main conveyor belt stripping device employs a dual-servo drive structure for more precise positioning control.
-
Splicing process utilizes vision + robotic solution, to superior splice quality and enhanced production efficiency.
-
Rolling operation achieves a fully automated rolling process, requiring only the operator to change the cart.
-
The rolling mechanism features automatic angle rotation functionality.
Equipment Parameters:
|
Item |
Parameter |
|
Cutting Angle |
0–67°, 90° |
|
Cut Width |
Max. 1450mm |
|
Cutting Speed |
Max. 18 cuts/minute (at 0°, width 460mm) |
|
Ply Thickness |
0.6–1.6mm |
|
Splicing Efficiency |
Max. 13 splices/minute (with hypotenuse length of 450mm) |
Equipment Accuracy:
|
Item |
Accuracy |
|
Cutting Angle Deviation |
±1° |
|
Cut Width Deviation |
±1mm |
|
Splicing Width Deviation |
±1mm |
|
Splicing Misalignment Deviation |
±1mm |
